DESCRIBE
Horizontal membrane pneumatic presses, available in small, medium or large sizes. Reliability, versatility of application and simple controls make this a consistently successful product, able to satisfy any requirements.
The pressure membrane is made of food-grade PVC while the frame and all surfaces that come into contact with the must are made of AISI 304 stainless steel. The entire process is managed from the touch-screen control panel, and can be operated in manual or automatic modes.
The pneumatically powered marc extraction hatch can be opened manually or automatically.
PA8
Very compact pneumatic presses with horizontal membrane and tank capacities of 8HL. The pressing membrane is in food-compatible PVC while the frame and all surfaces in contact with the must are in AISI 304 stainless steel. All processing phases are completely controlled by PLC, with the option of working in either manual or automatic mode from the control panel fitted to the machine.
PA14/PA20
Small sized pneumatic presses with horizontal membrane and tank capacities of 14 and 20 hectolitres respectively. The pressing membrane is in food-compatible PVC while the frame and all surfaces in contact with the must are in AISI 304 stainless steel. All processing phases are completely controlled by PLC, with the option of working in either manual or automatic mode from the control panel fitted to the machine.
Also available in the ‘open’ version, on which the tank is equipped with drain holes direct to the outside.
PA28/ PA38/PA38S/PA50/PA50S
Medium sized pneumatic presses with horizontal membrane and tank capacities of 28, 38 and 50 hectolitres respectively. The pressing membrane is in food-compatible PVC while the frame and all surfaces in contact with the must, including the inner draining surfaces, are in AISI 304 stainless steel. All processing phases are completely controlled by PLC, with the option of working in either manual or automatic mode from the control panel fitted to the machine.
Marc evacuation door with manual opening and by automatic command on models PA 38 S and PA 50 S.
Also available in the ‘open’ version, on which the tank is equipped with drain holes direct to the outside.
PA65/PA80/PA110/PA160/PA250/PA360/PA450
Medium sized pneumatic presses with horizontal membrane and tank capacities of 65, 80, 110, 160, 250, 360 and 450 hectolitres respectively. The pressing membrane is in food-compatible PVC while the frame and all surfaces in contact with the must, including the inner draining surfaces, are in AISI 304 stainless steel. All processing phases are completely controlled by PLC, with the option of working in either manual or automatic mode from the control panel. PA 65, 80 and PA 110 models are also available in the ‘open’ version, on which the tank is equipped with drain holes direct to the outside.
